| Material | BK7 or other optical materials |
| Dimension specification | 7×7, 8×8, 10×10, can also be customized |
| Dimensional tolerance | ±0.1mm |
| 90° degree Comprehensive angle | <20 " ,30" ,1' |
| Surface Flatness | < λ /10@632.8nm |
| Surface quality | 60/40 or higher |
| Coating | Silver, aluminum, dielectric coating + protective painting; AR |
| Clear aperture | >90% |
| Reflectivity | >95% |
| Material | BK7 or other optical materials |
| Dimension specification | 7×7, 8×8, 10×10, can also be customized |
| Dimensional tolerance | ±0.1mm |
| 90° degree Comprehensive angle | <20 " ,30" ,1' |
| Surface Flatness | < λ /10@632.8nm |
| Surface quality | 60/40 or higher |
| Coating | Silver, aluminum, dielectric coating + protective painting; AR |
| Clear aperture | >90% |
| Reflectivity | >95% |
