| Quantity: | |
|---|---|
| Material | Sapphire,fused silica,BK7 |
| Dimension specification | Common 12×68×1, 15×68×1 |
| Dimensional tolerance | ±0.05-.1mm |
| Parallel difference | 20" |
| Surface quality | 60/40 or higher |
| Minimum transmittance | T>90% |
| Cut-off depth | T<0.1% |
| Center wavelength deviation | ±5nm |
| Anti damage threshold | 300MW/cm2CW,1J/cm2pulsed |
| Transmitted wavelength band | 410\420\480\510\530\560\590\610\640\690\700\750 can also be customized |
| Material | Sapphire,fused silica,BK7 |
| Dimension specification | Common 12×68×1, 15×68×1 |
| Dimensional tolerance | ±0.05-.1mm |
| Parallel difference | 20" |
| Surface quality | 60/40 or higher |
| Minimum transmittance | T>90% |
| Cut-off depth | T<0.1% |
| Center wavelength deviation | ±5nm |
| Anti damage threshold | 300MW/cm2CW,1J/cm2pulsed |
| Transmitted wavelength band | 410\420\480\510\530\560\590\610\640\690\700\750 can also be customized |
