| Quantity: | |
|---|---|
| Diameter (mm): | 12.50 /25.0 /50.0 +0.00/-0.10 |
| Center Wavelength CWL (nm): | 532/540/600/785/808 |
| Minimum Transmission (%): | 90 |
| Optical Density OD (Average): | ≥4.0 |
| Coating: | Hard Coated |
| Blocking Wavelength Range (nm): | 250 - 1100 |
| Surface Quality: | 60-40 |
| Angle of Incidence (°): | 0±5 |
| Substrate: | Fused Silica |
| Transmitted Wavefront, RMS: | λ/4 |
| Diameter (mm): | 12.50 /25.0 /50.0 +0.00/-0.10 |
| Center Wavelength CWL (nm): | 532/540/600/785/808 |
| Minimum Transmission (%): | 90 |
| Optical Density OD (Average): | ≥4.0 |
| Coating: | Hard Coated |
| Blocking Wavelength Range (nm): | 250 - 1100 |
| Surface Quality: | 60-40 |
| Angle of Incidence (°): | 0±5 |
| Substrate: | Fused Silica |
| Transmitted Wavefront, RMS: | λ/4 |
